Coffee Machine Water Tank Shell OEM — Deep Drawn 304
Deep-drawn 304 stainless water tank shells for coffee machine OEM. Mouth/neck geometry and food-contact finishes follow your STEP/PDF — we form metal shells, not full plastic rese… Read full overview
- Focus — Water tank metal shell / liner
- Process — Deep draw + trim + food-contact finish
- Material — Typically 304
- Mouth / neck — From your drawing
- Material
- SS201 / 304 / 316 (program-specific)
- Volume & MOQ
- MOQs are program-specific — share annual volume tiers for cavitation and landed pricing.
New geometry not previously produced?
Many OEM programs begin with new geometry. With 60+ owned molds, 200+ customer molds under management, multi-pass deep drawing capability, and DFM review, we assess whether your stainless shell can progress from sampling to serial production.
RFQ package should include:
- Engineering drawing or dimensional sample photos with critical dimensions
- Annual volume tiers and target delivery window
- Material grade, thickness, surface finish, and compliance market
- Critical mating and quality features: hub interface, weld load capacity, rim circularity, or cosmetic acceptance criteria
SGS / RoHS / REACH documentation available on request for qualified OEM programs.
Program overview
Deep-drawn 304 stainless water tank shells for coffee machine OEM. Mouth/neck geometry and food-contact finishes follow your STEP/PDF — we form metal shells, not full plastic reservoir assemblies.
What this program shows
- Deep-drawn tank shells and liners in food-grade stainless
- Mouth and sealing-related dimensions from your print
- Interior finish options for water contact
- Export documentation coordinated per PO when required
Provide tank envelope, neck details, and volume forecast. We return DFM, tooling class, and sample path.
See related reference programs under Coffee Equipment Components on this site — same factory, same drawing-based workflow. Related cards appear below when available.
Specifications
| Focus | Water tank metal shell / liner | Process | Deep draw + trim + food-contact finish |
|---|---|---|---|
| Material | Typically 304 | Mouth / neck | From your drawing |
| Leak-related dims | Criticals marked on print | Program type | Reference program — not stock SKUs |
Customization from drawing
Quoted from your engineering drawing or approved reference sample — not offered as ex-stock catalog items. Typical adjustable parameters for this forming family:
| Part types | Pitchers, drip trays, water tank shells, knock-box cups | Spout / drain | Geometry from your drawing |
|---|---|---|---|
| Surface finishes | Mirror interior options, brushed exterior, spray coat | Handle options | Single / custom weld on pitcher programs |
| Logo / marking | Laser engraving, etching, steel stamp, silk screen | Material | Typically 304 food-contact; 201/316 per RFQ |
| Program type | Drawing-based OEM/ODM |
Compliance & documentation
We support appliance and HORECA OEM programs with ISO 9001-aligned QC, material traceability, and third-party tests (LFGB, FDA-oriented food contact, RoHS, REACH) coordinated per purchase order. See our Quality & compliance section for the full documentation matrix.
View quality & complianceFAQ for B2B buyers
Drawing-based OEM programs — not retail or ex-stock catalog parts.
- Can this part be ordered as shown from inventory?
- No. Each page is a reference program that documents forming capability on comparable tooling. Your part is evaluated from the engineering drawing or sample — geometry, depth, and mating interfaces may differ.
- Can you manufacture a geometry you have not produced before?
- Yes. Many OEM programs begin with new geometry. We assess DFM, tooling route, and whether the stainless shell can progress from sampling to serial production.
- What inputs are required for a quotation-ready RFQ?
- Engineering drawing or dimensional sample photos, annual volume tiers and target delivery window, material grade / thickness / finish and compliance market, plus critical mating and quality features such as hub interface, weld load capacity, rim circularity, or cosmetic acceptance criteria.
- How are MOQs and lead times determined?
- MOQs and schedules are program-specific. Provide volume tiers and required delivery windows so we can align cavity count, tooling, and production planning.
- Do you provide compliance documentation?
- SGS / RoHS / REACH and food-contact oriented tests can be coordinated per qualified program and purchase order. Request the documentation matrix applicable to your target market.
- Is this website intended for household retail purchasers?
- No. We serve appliance brands, sourcing companies, and B2B importers on OEM deep-drawing and stamping programs.
Request a custom quotation
Submit your drawing-based requirements; sales engineering will return a feasibility assessment and recommended next steps. Please include:
- Engineering drawing or dimensional sample photos with critical dimensions
- Annual volume tiers and target delivery window
- Material grade, thickness, surface finish, and compliance market
- Critical mating and quality features: hub interface, weld load capacity, rim circularity, or cosmetic acceptance criteria
